 | 适应带宽mm | 额定吊高h≤mm | 物料厚度≤mm | 励磁功率≤kw | 适应带速≤mm | 外型尺寸mm | |||
A | B | Dφ | |||||||
RCDB-3 | 300 | 80 | 60 | 0.8 | 2.5 | 210 | 250 | 400 | |
RCDB-4 | 400 | 100 | 80 | 1 | 250 | 310 | 500 | ||
RCDB-5 | 500 | 150 | 100 | 1.5 | 295 | 350 | 610 | ||
RCDB-6.5 | 650 | 200 | 150 | 2.0 | 310 | 370 | 700 | ||
RCDB-8 | 800 | 250 | 200 | 3.6 | 340 | 390 | 930 | ||
RCDB-10 | 1000 | 3000 | 250 | 5 | 360 | 390 | 1100 | ||
RCDB-12 | 1200 | 350 | 300 | 6.8 | 385 | 420 | 1200 | ||
RCDB-14 | 1400 | 400 | 350 | 9 | 405 | 420 | 1650 | ||
RCDB-16 | 1600 | 450 | 400 | 13 | 460 | 450 | 1900 | ||
RCDB-18 | 1800 | 500 | 450 | 18 | 530 | 500 | 2150 | ||
